Item | Specifications |
Step Angle Accuracy | ±5% |
Resistance Accuracy | ±10% |
Inductance Accuracy | ±20% |
Temperature Rise | 80℃ Max |
Ambient Temperature | -20℃~+50℃ |
Insulation Resistance | 100MOMin 500VDC |
Dielectric Strength | 500V AC 1minute |
Allowable Radial Load | 0.02mm Max. (450g load |
Allowable Thrust Load | 0.08mm Max. (450g load) |
Model | Stepangle () | Length (mm) | Voltage V | Current A/phase | Resistance Ω/phase | Inductance mH/phase | Hold torque Nm | Rotor inertia g.cm² | weight kg |
42BYG250-34 | 1.8 | 34 | 2.76 | 1.2 | 2.3 | 2.5 | 0.21 | 35 | 0.22 |
42BYG250-40 | 40 | 2 | 1.2 | 1.67 | 3.7 | 0.3 | 54 | 0.3 | |
42BYG250-47 | 47 | 2.02 | 1.2 | 1.69 | 2.6 | 0.4 | 68 | 0.38 | |
42BYG250-60 | 60 | 3.3 | 1.2 | 2.75 | 6.4 | 0.6 | 102 | 0.5 |
